Picture of 4" Wide CornerMax® Pads Picture of 4" Wide CornerMax® Pads Picture of 4" Wide CornerMax® Pads

4" Wide CornerMax® Pads

Manufacturer: Lift-It
To be effective, conventional forms of sling protection must be of sufficient strength, thickness and construction. Traditional sling protection has always relied on these attributes to prevent damage to the sling because of direct contact with damaging load edges, corners or surfaces.
More...
SKU: CM-4
$68.49
i h
Fabrication Time: 3-5 days
Made in the USA

To be effective, conventional forms of sling protection must be of sufficient strength, thickness and construction. Traditional sling protection has always relied on these attributes to prevent damage to the sling because of direct contact with damaging load edges, corners or surfaces.

Patented CornerMax® Pads are truly remarkable because of the tunnel or "no touch zone" that is formed between the load corner and the CornerMax® Pad. The no touch zone greatly reduces the possibility of cutting. "Cut proof" sling protection does not exist. Note that the sides of the load must completely support CornerMax® Pads in order to create and maintain "the tunnel". CornerMax® Pad ratings are only valid if the 90 degree, CORNERED load fully engages the internal walls of the protector.
US Patent No. 7,744,138.



CornerMax® Pad
Stock Number

OVERALL WIDTH
(Inches)

ROD WIDTH *
(Inches)

SLING WIDTH
(Inches)

UNIT WEIGHT
(Lbs.)

CM-4

4

2

1 to 2 in.

1.10

CM-5

5

3

3 in.

1.35

CM-6

6

4

4 in.

1.65

CM-8

8

6

Up to 5 in.

2.10

CM-8

8

6

Up to 6 in.

2.10

CM-10

10

8

Up to 8 in.

2.70

CM-12

12

10

Up to 10 in.

3.35

CM-14

15

12

Up to 12 in.

5.50

CM-16

17

14

Up to 14 in.

6.50



* Use Rod Width for determining maximum loading. DO NOT use Pad Width.

Please Note: CornerMax® Pads are 10.25 inches in length, unless otherwise specified.



Do not exceed 25,000 Lbs. per inch of sling contact width. CornerMax® Pads are for use on 90 degree cornered Loads.

All goods are custom made and Non-returnable. Any return must be negotiated, include a return authorization number and will be subject to a restocking fee.
Warning See 'Product Resources' tab above for Warning Information

PROP 65 WARNING

Products made and/or supplied by Lift-It® Manufacturing can expose you to chemicals including Chromium, Formaldehyde, Cadmium, Lead, Lead based compounds DEHP, Nickel, Nickel compounds, Acrylamide, Crystalline Silica, Triethanolamine, N-Methyl-2-pyrrolidone, which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, go to: www.P65Warnings.ca.gov

>> Click here for more details <<
Products specifications
Made in USA Yes
Width (inches) 4"
Products specifications
Product Resources
Product Resource Product Spec Sling Protection
Product Resource Product Spec Safety Bulletin-English
Product Resource Product Spec Safety Bulletin-Spanish
Product Resource Product Spec CornerMax® Pad Safety Information
Product Resource Product Spec CornerMax® Pad Safety Information Espanol
