    CDI Williams Torque Multiplier - Planetary-Gear Mechanism

    Call for price
    *

    Features • Designed where high torques are necessary for fastening or breaking out stubborn fasteners. • Allows operator safe and easy means of producing torque for job requirements. • Precision planetary gear multiplies the operator’s input from standard torque wrenches. • Can also multiply the torque from air-driven (non-impact) wrenches.

    Fabrication Time: 3-5 days

    TORQUE MULTIPLIERS: PLANETARY-GEAR MECHANISM SPECIFICATIONS
    Stock

    Number
    Max Output

    (Ft. Lbs.)
    Input

    Cap.
    Gear

    Ratio
    Torque

    Ratio
    Input

    Female Sq.
    Output

    Sq. Size
    Overall

    Length
    Square to Top Head

    Dia.
    TM-290 750 227 4:1 3:3:1 1/2 3/4 8-1/2 3-1/4 2-13/16
    TM-391 1200 200 6:3:1 6:0:1 1/2 3/4 19-39/64 4 3-15/16
    TM-392 2200 162 15:0:1 13:6:1 1/2 1 19-39/64 5-3/4 4-1/16
    TM-393 3200 173 20:25:1 18:5:1 1/2 1 19-39/64 6-1/2 4-1/16

    All goods are custom made and Non-returnable. Any return must be negotiated, include a return authorization number and will be subject to a restocking fee.
